MIL-DTL-18714F (OS)
TABLE IV. Conformance inspection by classification of characteristics for stock and insulator assembly, drawing number 1275046
Conformance
Requirement
Inspection Method
Classification
Examination or Test
Criteria
Paragraph
Reference
None Defined
Critical
Major
Note 3: The primer stock insulator, find no. 2, shall be securely held in the
Level IV
3.2
M101
AIE
primer stock, find no. 1, by a 360° ring stake.
Note 4: Stock surface (datum C) shall be free of contamination and foreign
Level IV
3.2 & 3.10
M102
AIE
material that can cause poor electrical continuity.
Note 6: Insulator shall not protrude aft of datum C.
Level IV
3.2
M103
AIE
Note 7: The installed insulator shall have no splits, cracks, holes, or breaks.
Level IV
3.2 & 3.10
M104
AIE
Note 2: Surface texture, √ 125
Minor
Note 2: Remove all burrs
Level II
201
3.2
AIE
Note 2: Corners at I.D. of insulator 45° x .005 max
Level II
202
3.2 & 3.10
AIE
[Ø .002(M)][A(M)] (for Ø .176 +.003/-.000)
Level II
203
3.2
AIE
Note 5: Insulator shall not protrude forward of datum B of the stock. Surface
Level II
204
3.2
AIE
texture, √ 63
205
Level II
3.2
AIE
Ø .579 -A-
206
Level II
3.2
AIE
207
Level II
3.2
AIE
13
