MIL-DTL-18714F (OS)
TABLE VIII. Conformance inspection by classification of characteristics for electrode and insulator assembly, drawing number 584087
Conformance
Requirement
Inspection Method
Classification
Examination or Test
Criteria
Paragraph
Reference
Critical
None Defined
Major
M101
Ø .174 +.000/-.002
Level IV
3.2
AIE
M102
Note 5: There shall be no breaks, cracks, holes, or other imperfections.
Level IV
3.2 & 3.10
AIE
M103
.319 ± .001
Level IV
3.2
AIE
Minor
201
Note 3: Material: polyamide molding and extrusion material, ASTM D6779,
Level II
3.2
COC
group 5, class 1, grade 1, table S2.1, type III, grade E, A-24/23/50.
Note 4: Material: brass, IAW ASTM B36, composition optional, temper H02
202
or ASTM B16, temper H02.
Level II
3.2
COC
.033 max .030 min
203
Level II
3.2
AIE
[Ø .002(M)][B(M)] (for Ø .412 ± .001)
204
.054 ± .002
Level II
3.2
AIE
205
Ø .412 ± .001
Level II
3.2
AIE
Note 5: Surface texture √ 63 all machined surfaces
206
Level II
3.2
AIE
207
Ø .100 ± .002
Level II
3.2
AIE
208
[Ø .001(M)][A] -B- (for Ø .174 +.000/-.002)
Level II
3.2
AIE
209
[Ø .002(M)][C(M)] (for Ø .100 ± .002)
Level II
3.2
AIE
210
.259 ± .002
Level II
3.2
AIE
211
Note 5: Outside corners .01 x .01 chamfer max
Level II
3.2
AIE
212
Note 5: Fillets R .005 max
Level II
3.2
AIE
213
Note 5: Remove all burrs
Level II
3.2
AIE
214
Level II
3.2 & 3.10
AIE
17
