MIL-DTL-18714F (OS)
TABLE XIV. Conformance inspection by classification of characteristics for igniter assembly, drawing number 2434754
Conformance
Requirement
Inspection Method
Classification
Examination or Test
Criteria
Paragraph
Reference
Critical
Note 4: No explosive shall be present on any surface of the assembly other
C1
100%
3.2 & 3.10
AIE
than in the cavity.
Major
Note 2: Ignition charge, find no. 2, shall be loaded until charge is flush with
M101
Level IV
3.2
AIE
top of cavity and bridge-wire, find no. 1, is completely covered.
Note 3: The dried ignition charge shall be free from cracks and voids, and
M102
Level IV
3.2 & 3.10
AIE
must not separate from cavity. The charge shall entirely cover the
bridge-wire.
Minor
201
Note 5: Assembly shall be maintained at 15°C min, and 60% max relative
Level II
3.2
AIE
humidity until sealed into assembly, drawing 2434753.
26
