MIL-DTL-18714F (OS)
TABLE XX. Conformance inspection by classification of characteristics for ignition element, electric; MK 1 MOD 1 assembly, drawing
number 2434753
Conformance
Requirement
Inspection Method
Classification
Examination or Test
Criteria
Paragraph
Reference
Critical
AIE
3.2 & 3.10
100%
C1
Note 8: There shall be no explosives on exterior surfaces.
Major
AIE
3.2
Level IV
M101
Note 3: The electrode washer and igniter assembly, shall be dried 4 hours
minimum at a temperature of 38° to 49°C immediately preceding assembly.
AIE
3.2 & 3.4
Level IV
Note 4: Class 4 black powder, find no. 6, charge shall be 3.3 grains min.
M102
Moisture content of black powder shall be 0.70% max.
AIE
3.2
Level IV
Note 6: Assembly shall have 360° crimp.
M103
AIE
3.2 & 3.3
100%
Note 7: There shall be no holes, cracks, splits, or breaks in the ignition
M104
element cup or exposed closing disc, find no. 4, after assembly. The
closing disc shall be under the crimped ignition element cup 360°.
AIE
3.2, 3.5 & 3.6
100%
Note 9: The assembly shall have an electrical resistance of .10 to .18 ohms.
M105
32
