MIL-DTL-18714F (OS)
TABLE XVI. Conformance inspection by classification of characteristics for electrode washer and igniter assembly, drawing number
3208374
Conformance
Requirement
Inspection Method
Classification
Examination or Test
Criteria
Paragraph
Reference
Critical
None Defined
Major
M101
Note 2: Electrode washer shall not extend over (Ø .4100) ignition cup.
100%
3.2
AIE
M102
Note 3: Electrode washer shall not be split, cracked, or broken after
Level IV
3.2 & 3.10
AIE
assembly.
-M103
.006 ± .006
Level IV
3.2
AIE
Minor
201
.006 + .006 (Upper Tol)
Level II
3.2
AIE
28
