MIL-DTL-18714F (OS)
TABLE XIII. Conformance inspection by classification of characteristics for ignition charge, drawing number 2434757
Conformance
Requirement
Inspection Method
Classification
Examination or Test
Criteria
Paragraph
Reference
None Defined
Critical
Major
COC1/
Note 2: Ignition charge composition:
M101
Level IV
3.2
A)
Normal lead styphnate...........98.00± .05% by weight
B)
Nitrocellulose.....................2.00± .05% by weight
C)
Butyl acetate......................as required
Note 3: The ignition charge shall be a homogeneous compound. Butyl
M102
Level IV
3.2
COA
acetate, find no. 3, shall be added as a wetting agent to make a uniformly
wetted paste which is suitable for loading. No free liquid shall be present
after mixing. Paste consistency shall be adjusted by addition or
evaporation of the butyl acetate. Any adjustment shall be followed by a
thorough remixing.
None Defined
Minor
1/
COC for the Ignition Compound shall include the following information for each ingredient: Specification, Manufacturer, and
Manufacturer's lot number, and whether there are any deviations from the requirements of their respective specifications.
25
