MIL-DTL-18714F (OS)
TABLE XII. Conformance inspection by classification of characteristics for bridge wire assembly, drawing number 2434752 Continued
Conformance
Requirement
Inspection Method
Classification
Examination or Test
Criteria
Paragraph
Reference
Minor
204
Note 12F: The wire shall be clean, smooth, and free from cracks or other
Level II
3.2 & 3.10
AIE
defects that may affect its serviceability.
205
Note 3: Wire shall be soldered in a manner such that the wire is not taut
Level II
3.2
AIE
between each solder joint.
206
Note 4: Ignition cup soldered surfaces shall be flush with their respective
Level II
3.2
AIE
component surfaces after excess solder is removed.
207
Note 5: There shall not be cold solder joints.
Level II
3.2 & 3.3
AIE
208
Note 5: The solder shall adhere firmly and smoothly to the parts joined.
Level II
3.2 & 3.3
AIE
209
Note 5: The joint shall not be chalky in appearance, or lacking metallic
Level II
3.2 & 3.3
AIE
luster.
210
Note 5: The joint shall not have a rough, gritty or piled-up surface.
Level II
3.2 & 3.3
AIE
211
Note 5: There shall be no solder in the ignition cavity.
Level II
3.2 & 3.3
AIE
24
