MIL-DTL-18714F (OS)
TABLE XVIII. Conformance inspection by classification of characteristics for closing disc, drawing number 2846969
Conformance
Requirement
Inspection Method
Classification
Examination or Test
Criteria
Paragraph
Reference
Critical
None Defined
Major
M101
.0050± .0004
Level IV
3.2
AIE
-M102
Ø .536± .001
Level IV
3.2
AIE
M103
Note 4: There shall be no holes, splits, cracks, or breaks.
Level IV
3.2 & 3.3
AIE
Minor
201
Note 2: Finish as rolled or punched.
Level II
3.2
AIE
202
Material: Brass, IAW ASTM B36, composition optional, temper H01 or H02
Level II
3.2
COC
203
Note 3: Remove all burrs.
Level II
3.2 & 3.10
AIE
30
