MIL-DTL-18714F (OS)
TABLE XXI. Conformance inspection by classification of characteristics for primer tube, drawing number 685475 and MIL-DTL-15119A
Continued
Conformance
Requirement
Inspection Method
Classification
Examination or Test
Criteria
Paragraph
Reference
Drawing 685475
(continued)
Minor
203
R .04
204
.085 min
Level II
3.2
AIE
205
.240 ± .010
Level II
3.2
AIE
206
.055 min
Level II
3.2
AIE
207
Ø .630 ± .008
Level II
3.2
AIE
― [ Ø .030 (M)] (for Ø .760 +.010/-.000)
208
Level II
3.2
AIE
209
.05 ± .02
Level II
3.2
AIE
210
20.250 ± .020
Level II
3.2
AIE
211
R .025 or 45° x .025
Level II
3.2
AIE
212
1.00 ± .03
Level II
3.2
AIE
213
45° x .020 ± .005
Level II
3.2
AIE
214
Note 2: Fillets R .010 max
Level II
3.2
AIE
215
Note 2: Outside corners 45° x .02 max
Level II
3.2
AIE
216
Note 2: Remove all burrs
Level II
3.2
AIE
217
15 x .75
Level II
3.2 & 3.10
AIE
Level II
3.2
AIE
MIL-DTL-15119
Critical
C1
Hydrostatic test to 18,000 PSI min.
100%
3.2
AIE
Major
M101
Manufacture. The tubing shall be drawn from fully killed steel
manufactured by either the open hearth or electric furnace process.
Level IV
3.2
COC
35
