MIL-DTL-18714F (OS)
TABLE XXV. Conformance inspection by classification of characteristics for closing cup, drawing number 2847019 Continued
Conformance
Requirement
Inspection Method
Classification
Examination or Test
Criteria
Paragraph
Reference
Minor
Note 3: Over time, cup dimensions may shift due to release of internal
Level II
3.2
211
NSIG
stresses and effects of humidity. However, the cup will still satisfy its
functional requirements at the next level of assembly, which is verified by
satisfying the "constrained state" (see note 5).
Note 4: The side walls of the cup shall be pliable to allow proper function
Level II
3.2
212
NSIG
of the cup in the next higher assembly, as described in the "constrained
state" requirement.
Note 6A: Verification requirements of MIL-DTL-18714 shall be met by
Level II
213
3.2
COC
certification of compliance for material; note 2.
Note 6B: Verification requirements of MIL-DTL-18714 shall be met by
214
Level II
3.2
AIE
manufacturer's data showing dimensional compliance in "free state"; note
3.
Note 6C: Verification requirements of MIL-DTL-18714 shall be met by
215
Level II
3.2
NSIG
compliance of "constrained state"; note 5.
Verification requirements for first article inspection shall be met by the
Level IV & II
3.2
AIE/NSIG
NOTE
"constrained state". Manufacturer's data showing dimensional
compliance at time of manufacture pertains to the "free state".
