MIL-DTL-18714F (OS)
TABLE XXVII. Conformance inspection by classification of characteristics for primer electric, MK 45 MOD 1 assembly, drawing number
2434755 Continued
Conformance
Requirement
Inspection Method
Classification
Examination or Test
Criteria
Paragraph
Reference
Minor
201
Note 2: Ignition element, find no. 2, shall be sealed in two places,
Level II
3.2
AIE
360° around, with moisture proof varnish, find no. 8.
202
Note 16: Varnish shall be dry prior to packaging.
Level II
3.2
AIE
203
Note 19: The manufacturer shall take precautions during loading to ensure
Level II
3.2 & 3.4
AIE
the black powder in the loaded primer does not exceed the maximum
moisture content requirement (0.70% by weight).
204
Surface Primer, IAW ASTM D5363, Grade N.
Level II
3.2
COC
205
Black Powder, Class 2, IAW MIL-P-223.
Level II
3.2
COA
206
Sealing Compound, IAW ASTM D5363, AN0121 or AN0123.
Level II
3.2
COC
207
Moisture proof varnish, IAW MIL-V-16399.
Level II
3.2
COC
208
Note 2: Varnish shall not prevent contact between the primer stock inner
Level II
3.2
AIE
face and the outer face of the ignition element cup, electrode end (2A).
209
Note 15: The stock and the electrode shall be used as terminals. 15 to 20
lb force shall be applied to the electrode during resistance measurement.
Level II
3.2
AIE
48
