MIL-DTL-18714F (OS)
TABLE XXVII. Conformance inspection by classification of characteristics for primer electric, MK 45 MOD 1 assembly, drawing number
2434755 Continued
Conformance
Requirement
Inspection Method
Classification
Examination or Test
Criteria
Paragraph
Reference
Major
M103
Note 7: There shall be no sealing compound on primer electrode or the
Level IV
3.2
AIE
external threads of the primer stock.
M104
Note 5: Electrode and insulator shall not protrude forward of stock surface,
100%
3.2
AIE
datum A. 100% inspection required.
M105
Note 6: Depth of electrode below stock surface, datum A, shall be .018
100%
3.2
AIE
max. 100% inspection.
M106
Note 8: Black powder shall be checked during primer production to assure
Level IV
3.2 & 3.4
AIE
conformance with MIL-DTL-18714, paragraph 3.4.
M107
Note 9: Class 2 black powder charge shall be [50.5 53.1 grams].
Level IV
3.2
AIE
M108
Note 10: During assembly, inner cup, find no. 9, shall be located firmly
Level IV
3.2
AIE
against black powder. Cup shall not be cocked or tilted. Primer tube liner
shall not be torn or crumpled.
M109
Note 11: After application of approximately 3 cc of type B moisture proof
Level IV
3.2
AIE
varnish, find no. 8, to inner cup so that the lip of the cup is covered by
varnish, the primer shall be inverted and permitted to drain for 15 minutes
minimum. A bead of varnish shall be formed 360° around the lip of the
inner cup.
46
