MIL-DTL-18714F (OS)
TABLE XXVI. Conformance inspection by classification of characteristics for cup, inner, drawing number 3208399
Conformance
Requirement
Inspection Method
Classification
Examination or Test
Criteria
Paragraph
Reference
Critical
None Defined
Major
-M101
.016 ± .004
Level IV
3.2
AIE
M102
Ø .610 +.020/-.000 AVG
Level IV
3.2
AIE
M103
"Constrained state" requirement: when assembled in the mating primer
Level IV
3.2
NSIG
tube liner and plug assembly, the side walls of the cup shall form a 360°
seal without forming any furrows, gaps or open channels. Navy gage no.
6656381 may be used to verify the constrained state.
Minor
201
.510 +.030/-.010 (T) to R .080
Level II
3.2
AIE
202
[.01] (F) (for dim .510 +.030/-.010 (T) to R .080)
Level II
3.2
AIE
203
R .080 +.040/-.030
Level II
3.2
AIE
204
.016 + .004 (Upper Tol)
Level II
3.2
AIE
205
.500 ± .030
Level II
3.2
AIE
206
.045 +.015/-.030 AVG
Level II
3.2
AIE
207
Note 2: Material: insulation, electrical, paper, MIL-I-695, Type R.
Level II
3.2
COC
208
Note 3: Dimensions apply to cup, inner in "free state" at the time it is
Level II
3.2
AIE
manufactured.
43
