MIL-DTL-18714F (OS)
TABLE XXIV. Conformance inspection by classification of characteristics for primer tube, liner and plug assembly, drawing number
685477
Conformance
Requirement
Inspection Method
Classification
Examination or Test
Criteria
Paragraph
Reference
Critical
None Defined
Major
M101
Note 3: No paper liner shall be visible in holes, see notes 8, 9, and 10. Pin
Level IV
3.2
AIE
holes and cracks in the sealant which can be penetrated by a pin of Ø .020
inch diameter to a depth of .050 inch are not acceptable.
M102
Note 4: Plug, find no. 4, shall be press fit into tube, and shall be seated
Level IV
3.2
AIE
against tube at, at least one point.
M103
Note 5: After assembly, the liner shall not be torn or crumpled.
Level IV
3.2
AIE or NSIG
M104
Major Ø .7499 max
Level IV
3.2
AIE
M105
Note 6: The (Ø .200) hole in the plug after assembly with all other parts
Level IV
3.2
AIE
shall be [free of all obstructions].
M106
[Ø .005(M)][A(M)] (for dim Ø .584)
Level IV
3.2
AIE
Minor
201
.15 max
Level II
3.2
AIE
202
Purple Lacquer IAW MIL-L-296
Level II
3.2
COA
203
After inserting liner, holes shall be sealed with purple lacquer.
Level II
3.2
AIE
40
