MIL-DTL-18714F (OS)
TABLE XXII. Conformance inspection by classification of characteristics for primer tube liner, drawing number 2847020
Conformance
Requirement
Inspection Method
Classification
Examination or Test
Criteria
Paragraph
Reference
Critical
None Defined
Major
M101
.0035 +.0010/-.0005
Level IV
3.2
AIE
+M102
2.500 ± .030
Level IV
3.2
AIE
Minor
201
18.00 ± .06
Level II
3.2
AIE
202
Note 2: Material; bond paper, A-A-2804, type II. Approximate weight of
Level II
3.2
COC
1000 sheets (17 x 22) is 32 lbs. Alternate: paper, sealing IAW
MIL-P-60169, type II.
Grain of paper ↨
203
Level II
3.2
AIE
204
2.500 -.030 (Lower Tol)
Level II
3.2
AIE
37
