MIL-DTL-18714F (OS)
TABLE XXVII. Conformance inspection by classification of characteristics for primer electric, MK 45 MOD 1 assembly, drawing number
2434755
Conformance
Requirement
Inspection Method
Classification
Examination or Test
Criteria
Paragraph
Reference
Critical
C1
Note 3: Prior to assembly:
AIE
3.2 & 3.10
100%
(A) Mating surfaces shall be free of contamination or foreign
material.
AIE
3.2
100%
(B) Surface primer, find no. 4, shall have been applied to mating
threads of stock and insulator assembly, find no. 1, and primer
tube, liner and plug assembly, find no. 3, and dried for 15 minutes
minimum at 70 ± 10°F minimum.
AIE
3.2
100%
(C) Primer tube threads shall be coated 360° around with sealing
compound, find no. 5. Sufficient sealing compound shall be
applied so that a minimum of 75% of the engaged thread will be
coated.
AIE
3.2
100%
Note 4B: The stock and insulator assembly with ignition element installed
C2
shall not rotate on the primer tube, liner and plug assembly when 22 ± 2
ft-lbs reverse torque is applied.
AIE or NSIG
3.2
100%
9.1 min
C3
AIE
3.2 & 3.10
100%
Note 14: No explosive particles shall be present on exterior surfaces.
C4
45
