MIL-DTL-18714F (OS)
TABLE XXIII. Conformance inspection by classification of characteristics for plug, drawing number 685405
Conformance
Requirement
Inspection Method
Classification
Examination or Test
Criteria
Paragraph
Reference
Critical
None Defined
Major
+M101
Ø .700 +.000/-.004
Level IV
3.2
AIE
-M102
1.217
Level IV
3.2
AIE
M103
.302 ± .005
Level IV
3.2
AIE
M104
.125 +.002/-.000
Level IV
3.2
AIE
+M105
Chamfer 45° x .030 ± .010
Level IV
3.2
AIE
M106
Ø .584 +.003/-.000
Level IV
3.2
AIE
M107
Ø .200 thru
Level IV
3.2
AIE
M108
R .02 max
Level IV
3.2
AIE
M109
Ø .5993 +.0005/-.0000
Level IV
3.2
AIE
Minor
Note 2: Surface texture, √ 125
201
Level II
3.2
AIE
202
[Ø .002 (M)][A(S)] (for dim Ø .700 +.000/-.004)
Level II
3.2
AIE
203
[Ø .003 (M)][A(S)] (for dim Ø .584 +.003/-.000)
Level II
3.2
AIE
204
R .015
Level II
3.2
AIE
205
[Ø .010 (M)][A(M)] (for dim Ø .200 thru)
Level II
3.2
AIE
206
45° x .05
Level II
3.2
AIE
207
45° x .005 max
Level II
3.2
AIE
208
R .01 max
Level II
3.2
AIE
209
30°
Level II
3.2
AIE
210
.125 +.010/-.000
Level II
3.2
AIE
211
[.001][A]
Level II
3.2
AIE
212
Note 3: Material; Brass, IAW ASTM B36, composition optional, temper H02
Level II
3.2
COC
to H04, or ASTM B16, temper H02 to H04.
38
