MIL-DTL-18714F (OS)
TABLE XV. Conformance inspection by classification of characteristics for electrode washer, drawing number 584107
Conformance
Requirement
Inspection Method
Classification
Examination or Test
Criteria
Paragraph
Reference
Critical
None Defined
Major
M101
There shall be no splits, cracks, or breaks.
Level IV
3.2 & 3.10
AIE
-M102
Ø .397 +.000/-.003
Level IV
3.2
AIE
M103
Ø .176 +.003/-.000 thru
Level IV
3.2
AIE
Minor
201
.010 ± .002
Level II
3.2
AIE
202
Note 3: Material; nylon per ASTM D4066, or Cirlex ® .010 inch
Level II
3.2
COC
203
[Ø .002(M)][A(M)] (for dim Ø .176 +.003/-.000 thru)
Level II
3.2
AIE
204
Note 2: Remove all burrs
Level II
3.2 & 3.10
AIE
Note 2: Surface texture, √ 125
205
Level II
3.2
AIE
206
Ø .397 +.000 (Upper Tol)
Level II
3.2
AIE
27
