MIL-DTL-0048669A (AR)
Conformance Inspection
CLASSIFICATION OF CHARACTERISTICS
PARAGRAPH
TITLE
DRAWING NUMBER
8886365
4.4.2.3
Verge Assembly
SHEET 1 OF
1
NEXT HIGHEST
ASSEMBLY
8886357
CONFORMANCE REQUIREMENT PARAGRAPH REFERENCE
CRITERIA
PARAGRAPH
/ INSPECTION METHOD
CLASSIFICATION
EXAMINATION OF TEST
CRITICAL
None defined
MAJOR
101.
Bearing diameters (see Dwg. 8886367)
Level IV
3.2
Gage
102.
Thickness of verge (see Dwg. 8886366)
Level IV
3.2
Gage
103.
Outside diameter of verge (see Dwg
Level IV
3.2
Gage
8886366)
104.
Depth of cutout on verge (see Dwg. 8886366)
Level IV
3.2
Gage
105.
Distance from shoulder of arbor to end of
Level IV
3.2
Gage
bushing
106.
Perpendicularity of verge with bearing
Level IV
3.2
Gage
diameter
107.
Torque test
Level III
3.2
4.5.6
108.
Disassembly test
Level III
3.2
4.5.7
MINOR
201.
Lubricant missing
Level II
3.2
Visual
202.
Evidence of poor workmanship
Level II
3.13
Visual/4.5.22
NOTES:
10
