MIL-DTL-0048669A (AR)
Conformance Inspection
CLASSIFICATION OF CHARACTERISTICS
PARAGRAPH
TITLE
DRAWING NUMBER
8886357
4.4.2.7
Escapement Assembly
SHEET 1 OF
1
NEXT HIGHER
ASSEMBLY
----------------
CONFORMANCE REQUIREMENT PARAGRAPH REFERENCE
CRITERIA
PARAGRAPH
/ INSPECTION METHOD
CLASSIFICATION
EXAMINATION OR TEST
CRITICAL
1.
Arming time, min
100%
3.4
AAIE/4.5.1, 4.5.12
2.
Rotor in armed or partially armed position 1/
100%
3.2
AAIE/4.5.1
3.
Non-arming
100%
3.5
AAIE/4.5.1, 4.5.13
4.
Detent spring missing
100%
3.2
AAIE/4.5.1
5.
Detent missing
100%
3.2
AAIE/4.5.1
6.
Setback spring missing
100%
3.2
AAIE/4.5.1
7.
Setback pin missing or retracted 2/
100%
3.2
AAIE/4.5.1
8.
Pinion or verge assembly missing
100%
3.2
AAIE/4.5.1
9.
Transportation vibration
5/
3.7
4.5.14, 4.5.20
10.
Jolt
5/
3.8
4.5.16, 4.5.20
11.
Jumble
5/
3.9
4.5.17, 4.5.20
12.
Detent not engaged in teeth of sector gear 3/
100%
3.2
AAIE/4.5.1
13.
Setback pin not blocking rotor 4/
100%
3.2
AAIE/4.5.1
Non-Functioning
5/
3.11
4.5.19
14.
MAJOR
101.
Arming test
100%
3.3
4.5.11
102.
Functioning
5/
3.10
4.5.18
103.
Pin retraction and spring removal test
100 6/
3.6
4.5.15
104.
Improper maximum height at 3 places (120
Level IV
3.2
Gage
degrees apart) from base of escapement
housing to top plate
MINOR
201.
Face of posts above flush after stake
Level II
3.2
Gage
202.
Evidence of poor workmanship
Level II
3.13
Visual/4.5.22
NOTES:
1/ See 6.4 for definition of armed and partially armed.
2/ A retracted setback pin is a setback pin in an escapement assembly with the dimension (excluding
cut off nib) from the top of it to the bottom of the escapement housing, Dwg. 8886358, being 0.040 or greater.
3/ Either the protrusion of the detent into the sector gear teeth or the seating of the detent in its forward
position shall be inspected.
4/ The setback pin shall be checked to be blocking the rotor in accordance with Dwg. 8886357.
5/ This requirement is tested at higher assembly. See MIL-DTL-48683 (M918 TP; Projectile
Assembly) or MIL-DTL-50869 (M550 Fuze Less Spitback Assembly) for quantities.
6/ Accept on zero (0) and reject on one (1).
14
