MIL-DTL-0048669A (AR)

Conformance Inspection

CLASSIFICATION OF CHARACTERISTICS

PARAGRAPH

TITLE

DRAWING NUMBER

9219871

4.4.2.5

Rotor and Gear Sector Assembly

SHEET 1 OF 1

NEXT HIGHER

ASSEMBLY

8886363

PARAGRAPH

CONFORMANCE REQUIREMENT

REFERENCE

CRITERIA

PARAGRAPH

CLASSIFICATION

EXAMINATION OR TEST

/ INSPECTION METHOD

CRITICAL

None defined

MAJOR

101.

Static push off test

32 1/

3.2

4.5.10

102.

Parallelism of rotor to gear sector

Level IV

3.2

Gage

MINOR

201.

Evidence of poor workmanship

Level II

3.13

Visual/4.5.22

NOTES:

1/ Accept on zero (0) and reject on one (1).
