MIL-DTL-0048669A (AR)
Conformance Inspection
CLASSIFICATION OF CHARACTERISTICS
PARAGRAPH
TITLE
DRAWING NUMBER
8886368
4.4.2.4
Pinion Assembly
SHEET 1 OF1
NEXT HIGHER
ASSEMBLY
8886357
CONFORMANCE REQUIREMENT PARAGRAPH REFERENCE
CRITERIA
PARAGRAPH
/ INSPECTION METHOD
CLASSIFICATION
EXAMINATION OR TEST
CRITICAL
None defined
MAJOR
101.
Bearing diameter (2) (See Dwg. 8886369)
Level IV
3.2
Gage
102.
Starwheel thickness (See Dwg. 8886370)
Level IV
3.2
Gage
103.
True position of outside diameter
Level IV
of starwheel with bearing diameters
3.2
Gage
104.
Distance from top of pinion to top of bushing
Level IV
3.2
Gage
105.
Perpendicularity of starwheel with
Level IV
3.2
Gage
bearing diameters
106.
Push off test
Level III
3.2
4.5.8
107.
Torque test
Level III
3.2
4.5.9
MINOR
201.
Lubricant missing
Level II
3.2
Visual
202.
Evidence of poor workmanship
Level II
3.13
Visual/4.5.22
NOTES:
11
