MIL-DTL-0050869F (AR)
Conformance Inspection
CLASSIFICATION OF CHARACTERISTICS
PARAGRAPH
TITLE
DRAWING NUMBER
9266692
4.4.2.8
Centerplate Assembly
SHEET 1 OF
1
NEXT HIGHER
ASSEMBLY
8886355
PARAGRAPH
CONFORMANCE REQUIREMENT
CLASSIFICATION
EXAMINATION OR TEST
REFERENCE
CRITERIA
PARAGRAPH
/ INSPECTION METHOD
CRITICAL
None Defined
MAJOR
101.
Retention check of firing pin
Level III
3.2
4.5.6
102.
Pull off test of hammerweight assembly
80 1/
3.2
4.5.7
103.
Dislodging force test of hammerweight
80 2/
3.2
4.5.8
pins
104.
Firing pin retraction
Level III
3.2
4.5.9
MINOR
201.
Evidence of poor workmanship
Level II
3.9
Visual/4.5.22
NOTES:
1/ Accept on zero (0) and reject on one (1).
2/ The lot shall be rejected if the average separation force of the entire sample is less than the specified
average on the applicable drawing. If any one pin has a separation value less than the absolute
minimum specified on the applicable drawing the lot shall be rejected and set aside for disposition
in accordance with MIL-STD-1916.
16
