MIL-DTL-0050869F (AR)
Conformance Inspection
CLASSIFICATION OF CHARACTERISTICS
PARAGRAPH
TITLE
DRAWING NUMBER
9287616
4.4.2.11
Test Vehicle for M550 Fuze 1/
SHEET 1 OF
1
NEXT HIGHER
ASSEMBLY
9287615
PARAGRAPH
CONFORMANCE REQUIREMENT
CLASSIFICATION
EXAMINATION OR TEST
REFERENCE
CRITERIA
PARAGRAPH
/ INSPECTION METHOD
CRITICAL
None Defined
MAJOR
101.
Depth to charge surface
Level IV
3.2
Gage
102.
Concentricity of charge with small inside
Level IV
3.2
Gage
diameter of skirt
103.
Diameter of rotating bands
Level IV
3.2
Gage
104.
Security of test vehicle
Level III
3.2
4.5.18
105.
Chamber gage
100%
3.2
4.5.18/8827889,
8827890, 8827895
106.
Air pressure
Level III
3.2
4.5.20
107.
Specific gravity of inert material
Level III
3.2
4.5.17
(Dwg. 9287617)
MINOR
201.
Total length
Level II
3.2
Gage
202.
Perpendicularity of charge with small
Level II
3.2
Gage
inside Dia of skirt
203.
Depth to bottom of cavity
Level II
3.2
Gage
204.
Marking misleading or unidentifiable
Level II
3.2
Visual
205.
Color of skirt incorrect
Level II
3.2
Visual
206.
Evidence of poor workmanship
Level II
3.9
Visual/4.5.22
NOTES:
1/ All test vehicle components shall meet the Conformance Inspections slated in MIL-DTL-50872.
19
