MIL-DTL-50869 Fuze, Point Initiating, Base Detonating \(Pibd\) - M550, Less Spitback Assembly Loading, Assembling, And PackingThis specification covers the metal parts, assemblies, loading and assembling for one type of Fuze designated as Fuze, Point Initiating, Base Detonating: M550, Less Spitback Assembly.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 20 - 21 - 22


MIL-DTL-0050869F (AR)
Conformance Inspection
CLASSIFICATION OF CHARACTERISTICS
PARAGRAPH
TITLE
DRAWING NUMBER
8886356
4.4.2.1
Fuze Body
SHEET 1 OF
1
NEXT HIGHER
ASSEMBLY
8886355
PARAGRAPH
CONFORMANCE REQUIREMENT
CLASSIFICATION
EXAMINATION OR TEST
REFERENCE
CRITERIA
PARAGRAPH
/ INSPECTION METHOD
CRITICAL
None Defined
MAJOR
101.
Diameter setback spring cavity
Level IV
3.2
Gage
102.
Depth setback spring cavity
Level IV
3.2
Gage
103.
Diameter setback pin cavity
Level IV
3.2
Gage
104.
Depth setback pin cavity
Level IV
3.2
Gage
105.
Salt spray
1/
3.2
4.5.3
MINOR
201.
Evidence of poor workmanship
Level II
3.9
Visual/4.5.22
NOTES:
1/ Sampling and rejection shall be in accordance with MIL-C-5541.
9
